5 BBL Insulated Hot Liquor Tank | Gas Fired w/ Herms Coil

Glacier Tanks
Zoom Icon Click the image to zoom
Disclaimer: Images are intended to best approximate actual product
Brand Glacier Tanks
Stainless Steel SS304
Volume 5 Barrels (BBL)
Min. Total Volume 193.75 Gallons
Min. Working Volume 155 Gallons
Warranty 1 Year
Call Us: 360-953-8453
Contact Us

We specialize in custom tanks - Call us: 360-953-8453

Glacier Tanks Hot Liquor Tank Propane or Natural Gas Fired 5BBL (155GL) (585 L) with Herms Coil. Total volume 194 gallon (732 L). Heavy Duty Stainless Steel SS304. The Hot Liquor Tank Closed Top with removable Lid is a beautifully designed product for the discriminating brewer. Its features provide commercial brewery functionality at a consumer good price. 100% Stainless Steel.Quality Tanks at an affordable Price.. Money Back Guarantee on all Tanks except Special Order*Features Include:
  • Support Ring on Top
  • Full 3mm thickness
  • Removable Clamped Lid with CIP Port
  • Stainless Steel SS304
  • FireBox grated open bottom with 7'' Vent for Jet Burners(Non-UL Listed) Check with local codes (does not include jet burner)
  • Sight Level Tube with Valves
  • Thermowell and Thermometer
  • 1 ½''x 2'' Thru the Wall Spray Ball
  • Herms Coil with thru the wall adapter
  • 1 Yr Warranty
Optional Accessories:
  • Extra Ferules installed at $60.00 per ferule 1'' thru 2'' sizes
  • Extra Ferrules installed at $100.00 ea 3'' to 4''
  • 2'' Insulation Polyurethane with outer shell 2mm Add $900.00
  • Economite EC300 Forced Air Jet Burner $739.99
  • Special Closed 80mm Insulated Firebox with Perilite Insulation with Access Door with outer SS304 Clad layer. Add $750.00
  • Additional Details:
  • Please contact us for shipping quote, drawing specifications, and payment details prior to ordering at 503--253--5919. 70% Deposit at time of order. All fittings on special ordered tanks can be adjusted to your specifications. *See Warranty Information

Glacier Tanks will accept returns of website standard stocking items, but only if:

  1. The item is new, unused, and in resellable condition:
  2. You notify Glacier Tanks and request a return authorization within 14 days of your receipt of the item; and
  3. You return the item to Glacier Tanks, postage/shipping prepaid within 5 days of Glacier Tanks' return authorization (RMA).
  4. Special/custom order items are not returnable.

  5. Gaskets and seals are not returnable per FDA regulation.

After your items have been received by Glacier Tanks and verified to be unused, we will refund your purchase price, less shipping costs. Returns will incur a 15% restocking fee. Shipping costs are your responsibility and shall not be paid by Glacier Tanks.
