A mash tun converts the starches in crushed grains into sugars for fermenting. Most mash tuns have a false bottom and sparge arm so the sparging (or lautering) process can be performed in the same tank, thus extracting the sweet liquid called wort. Insulated Mash Tuns, which are highly recommended, help reach and maintain a consistent temperature while avoiding the potential scorching that can arise from a heat sources such a gas burners or electric elements.
Our mash tuns are available up to 30+ barrels which is ideal for craft brewers to commercial and industrial breweries, and a wide range of beverages and industries. We offer steam-jacketed, gas-fired and insulated commercial mash tuns. All mash tanks are constructed from food grade stainless steel SS304 with a 3-4 mm thickness, an interior sanitary finish with exterior side walls in a #4 dairy finish. All mash tuns come standard with 50% head space on top of working volume, and our 1 year warranty. All commercial tanks are beautifully designed for the discriminating brewer and loaded with many standard features that provide commercial brewery functionality for all brewers alike.
50% head space
1 Year Warranty
Minimum 3mm thick stainless steel body
Adjustable legs with oversize feet
Flat, hinged lid
Through the wall sparge arm adapter
Rectangular 13 in.; x 17 in.; side manway (Up to 7 BBL)
Rectangular 17 in.; x 21 in.; side manway (10 BBL+)
Perforated screen false bottom - 3mm thick
Fully Perlite insulated tank body with 2 in.; clad layer SS304
1.5 in.; drain
Sprayball for CIP
4 in.; grain in port
Valves, clamps, gaskets, thermometer, thermowell included
Optional 3-4mm milled screen upgrade
California Proposition 65 Information:
WARNING: This product can expose you to chemicals including Lead and lead compounds, which is known to the State of California to cause cancer. For more information go to www.p65warnings.ca.gov.
We would be happy to offer you a quote on a stock or custom tank. Choose one of our 3 easy options:
